进气口
1/2" FNPT
液体入口
32 mm (1-1/4")
液体排放
32 mm (1-1/4")
连接类型
NPT/BSPT (Threaded)
最大吸力提升能力
Rubber – 5.8 m (19.0') Dry, 8.0 (26.0') Wet
TPE – 5.2 m (17.0') Dry, 8.8 m (29.0') Wet
Full-Stroke PTFE – 6.4 m (21.0') Dry, 9.3 m (30.6') Wet
Reduced-Stroke PTFE – 3.7 m (12') Dry, 8.5 m (28') Wet
Ultra-Flex™ – 5.2 m (17.0') Dry, 8.5 m (28.0') Wet
最大工作流量
Rubber – 288 lpm (76 gpm)
TPE – 307 lpm (81 gpm)
Full-Stroke PTFE – 330 lpm (87.2 gpm)
Reduced-Stroke PTFE – 295 lpm (78 gpm)
Ultra-Flex™ – 269 lpm (71 gpm)
最大工作压力
8.6 bar (125 psi)
最大可通过固体直径
4.8 mm (3/16'')
输送量/行程 *
Rubber – 0.98 L (0.26 gal)
TPE – 1.1 L (0.29 gal)
Full-Stroke PTFE – 1.1 L (0.29 gal)
Reduced-Stroke PTFE – 0.53 L (0.14 gal)
Ultra-Flex™ – .76 L (0.20 gal)
* 1 cycle = 2 strokes
