进气口
1/2" FNPT
液体入口
38 mm (1-1/2")
液体排放
38 mm (1-1/2")
连接类型
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
最大吸力提升能力
Rubber – 5.5 m (18.2') Dry, 9.0 m (29.5') Wet
EZ-Install TPE – 4.8 m (15.9') Dry, 9.0 m (29.5') Wet
Full-Stroke PTFE – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet
Reduced-Stroke PTFE – 2.8 m (15.9') Dry, 9.0 m (29.5') Wet
最大工作流量
Rubber – 492 lpm (130 gpm)
EZ-Install TPE – 492 lpm (130 gpm)
Full-Stroke PTFE – 473 lpm (125 gpm)
Reduced-Stroke PTFE – 341 lpm (90 gpm)
最大工作压力
8.6 bar (125 psi)
最大可通过固体直径
6.4 mm (1/4”)
输送量/行程 *
Rubber – 1.2 L (0.32 gal)
TPE – 1.2 L (0.32 gal)
Full-Stroke PTFE – 1.1 L (0.28 gal)
Reduced-Stroke PTFE – 0.53 L (0.14 gal)
* 1 cycle = 2 strokes
