进气口
1/4" FNPT
液体入口
25 mm (1")
液体排放
25 mm (1")
连接类型
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
最大吸力提升能力
Rubber – 5.4 m (17.6') Dry, 9.3 (30.6') Wet
TPE – 4.1 m (13.6') Dry, 9.3 (30.6') Wet
Full-Stroke PTFE – 5.5 m (18.2') Dry, 9.0 m (29.5') Wet
Reduced-Stroke PTFE – 3.5 m (11.4') Dry, 9.3 m (30.6') Wet
最大工作流量
Rubber – 212 lpm (56 gpm)
TPE – 212 lpm (56 gpm)
Full-Stroke PTFE – 185 lpm (49 gpm)
Reduced-Stroke PTFE – 168 lpm (44 gpm)
最大工作压力
8.6 bar (125 psi)
最大可通过固体直径
6.4 mm (1/4'')
输送量/行程 *
Rubber – 0.30 L (0.08 gal)
TPE – 0.34 L (0.09 gal)
Full-Stroke PTFE – 0.3 L (0.08 gal)
Reduced-Stroke PTFE – 0.23 L (0.06 gal)
* 1 cycle = 2 strokes
