进气口
3/4" FNPT
液体入口
76 mm (3")
液体排放
76 mm (3")
连接类型
NPT/BSPT (Threaded)
DIN/ANSI (Flanged)
最大吸力提升能力
Rubber – 7.2 m (23.8’) Dry, 9.7 m (31.8’) Wet
EZ-Install TPE – 6.4 m (21.1') Dry, 9.7 m (31.8’) Wet
Full-Stroke PTFE – 6.2 m (20.2') Dry, 8.6 m (28.4') Wet
Full-Stroke PTFE (Ductile Iron) – 5.9 m (19.5') Dry, 9.7 m (31.7') Wet
最大工作流量
Rubber – 1,026 lpm (271 gpm)
EZ-Install TPE – 1,026 lpm (271 gpm)
Full-Stroke PTFE – 992 lpm (262 gpm)
Full-Stroke PTFE (Ductile Iron) – 874 lpm (231 gpm)
最大工作压力
8.6 bar (125 psi)
最大可通过固体直径
12.7 mm (1/2")
输送量/行程 *
Rubber – 5.1 L (1.35 gal)
EZ-Install TPE – 5.4 L (1.43 gal)
Full-Stroke PTFE – 5.0 L (1.32 gal)
Full-Stroke PTFE (Ductile Iron) – 4.8 L (1.26 gal)
* 1 cycle = 2 strokes
